Dismounting/mounting of the door
Generally, we do not recommend dismounting the door. If you do, you must be at least two persons,
so that one can hold the door, when the last screw is removed.
1. Swing out the door (see under "Cleaning the glass panel", point 1-4). THE DOOR MUST NOT
BE UNLOCKED WHILE WORKING WITH IT.
2. The door is swung out so that the 6.5 mm hole (1, fig. 9) on the left column is placed opposite
the hole in the inner tube (the door will then be ca. 1/3 open).
3. IMPORTANT! Put a screwdriver (2, fig. 10) with appropriate dimensions in the hole.
4. The 4 screws (3, fig. 9) in the doorframe can now be loosened. Support the door. When the
last screw has been removed, the door is free to be dismounted.
5. Mounting is to be done in reverse order.
2
1
3
Fig. 9
Fig. 10
