Replacement of the steering axes/counterweights
We recommend that this be done by the authorized SCAN-dealer. It is done in the following way:
1. Swing out the door or dismount it (it is only necessary to dismount the door when replacing the
left counterweight).
See under "Cleaning the glass panel", point 1-4 and under "Dismounting/mounting of the
door). THE LOCK OF THE CURRENT STEERING AXIS MUST NOT BE UNLOCKED
DURING THE WORK!
2. Turn the lower screw in the steering axis clockwise with a 2 mm key.
3. Raise the steering axis with the counterweight, lift off the counterweight and take it out
(diagonally, downwards).
4. Mounting is done in the reverse order. Tighten the lower screw of the steering axis.
Replacement part list
Caution: Use only original DSA 5 replacement parts. Do not use substitute materials.
Replacement part Part #
Glass panel for the door 57705011
Packet of ceramic gasket for door/glass 55999000 705
Upper baffle plate 54705000 091
Lower baffle plate 54705000 0911
Hearth stone back left 53999751 1
Hearth stone back right 53999751 2
Hearth stone front left 53999752 1
Hearth stone front right 53999752 2
Fire brick for firebox left side 53999753 1
Fire brick for firebox right side 53999753 2
Fire brick for firebox back wall 53999753 3
