SCAN DSA 5 - Specification; Technical information

7
Specification
Technical information
In order to protect the surface of the stove we recommend that you do not remove the plastic bag until
the installation has been completed.
inch mm
A 65 1650
B 34 1/2 876
C 24 1/4 617
D 9 1/2 243
Technical information
Output 63.000 BTU 19 kw
Min-Max output 27.500-63.000 BTU 8 - 19 kw
Size of room 1400 - 2900 Sq f 140 - 290 M
2
Fire box opening 16 7/8 x 22 5/8 inch 430 - 575 Mm
Flue outlet with built on adapter 6 inch 152 Mm
Weight 458 pound 208 kg
