Scantool 40BK - Change Tools

10
When changing the running direction of the spindle, forward to reverse or reverse
to forward, STOP THE MOTOR POWER first.
Absolutely do not change the spindle running direction when machine is running.
Improper operation of the switch may cause to the damage of switch, machine or
the danger to operator.
WARNING: CHANGE SPEED ONLY WHEN MACHINE IS STOPPED.
50 Hz
60 Hz
L1
105
90
L2
300
250
L3
390
325
H1
515
430
H2
1400
1170
H3
1820
1520
Change Tools
1. Removing Face Mill or Drill Chuck Arbor. Loosen the arbor bolt at the top of the spindle
shaft approximately 2 turns with a wrench. Rap the top of the arbor bolt with a mallet. After
taper has been broken loose, holding chuck arbor on hand and turn detach the arbor bolt
with the other hand.
2. To Install Face Mill or Cutter Arbor. Insert cutter and cutter arbor into the taper of spindle.
Tighten arbor bolt detach securely, but do not over tighten.
3. Removing Taper Drills.
a) Turn down the arbor bolt and insert the taper drill into the spindle shaft.
b) Turn the rapid down handle rod down until the oblong hole in the rack sleeve appears. Lind
up this hole with the hole in the spindle. Insert key punch key through holes and strike lightly
with a mallet. This will force the taper drill out.
Rpm
Levers
