Scantool 40BK - Parts List Model 40 Bks

33
Parts List Model 40 BKS
CODE
NO
PART NO
DESCRIPTION
SPECIFICATION
QTY
NOTE
1
2450002S
Head Body Set
1
2
2401001-2
Main Shaft Cover
1
3
6101
Chuck Arbor Bolt
MT3 M10xP1.5
1
3
6101-1
Chuck Arbor Bolt
MT3 M12xP1.75
1
3
6101-2
Chuck Arbor Bolt
MT3 W3/8”-16
1
3
6101-3
Chuck Arbor Bolt
MT3 W1/2”-12
1
3
6101-4
Chuck Arbor Bolt
R8 W7/16”-20
1
3
6101-5
Chuck Arbor Bolt
NT30 M12xP1.75
1
3
6101A
Chuck Arbor Bolt
MT4
1
4
HS207
Hex. Socket Head Screw
M4x0.7Px6L
2
For CE Only
5
HW102
Spring Washer
M4
2
For CE Only
6
Motor
1
7
S409
Hex. Socket Head Screw
3/8”-16UNCx1”L
3
8
HK027
Key
6x6x30L
1
9
6112
Rubber Flange
1
10
6116-2S
Pinion Assembly
MT3
1
10
6116-3S
Pinion Assembly
MT3 Heat treatment
1
10
6116-6S
Pinion Assembly
R8
1
10
61116BS
Pinion Assembly
R8 Heat treatment
1
10
6116-2NS
Pinion Assembly
NT30
1
10
6116-2SS
Pinion Assembly
1
Optinal
10
6116-2BS
Pinion Assembly
MT4
1
10-1
6114
Locknuts
2
10-2
HW205
Washer
AW06 § 30
1
10-3
CA30206J
Taper Roller Bearing
E30206J
1
10-4
6116-2
Rack Sleeve
MT3
1
10-4
6116-3
Rack Sleeve
MT3 Heat treatment
1
10-4
6116-6
Rack Sleeve
R8
1
10-4
6116B
Rack Sleeve
R8 Heat treatment
1
10-5
CA30207J
Taper Roller Bearing
30207J
1
10-6
6117
Spindle Shaft
MT3
1
10-6
6117-1
Spindle Shaft
MT3 Heat treatment
1
10-6
6117-2
Spindle Shaft
R8
1
10-6
6117-3
Spindle Shaft
NT30
1
10-6
6117-6
Spindle Shaft
R8 Heat treatment
1
10-6
2401017B
Spindle Shaft
MT4 Heat treatment
1
10-7
6119
Bearing Cap
MT3/MT4/R8
1
10-7
6119-1
Bearing Cap
NT30
1
11
61105S
Spring Base Set
1
13
S732
Cross Round Head Screw
3/16”x3/4”L
3
14
61103S
Spring & Spring Cover
1
15
W202
Spring Washer
¼”x1”x1.5t
2
16
W003
Washer
¼”
1
17
S471
Hex. Socket Head Screw
¼”x5/8L
1
18
6127
Screw Key
3/8”-16UNC-38L
1
19
N005
Hex. Nut
3/8”
1
20
2421003
Handle Rod
1
21
W002
Washer
½”x7/8”x”2t
1
22
6125-2
Fixed Tight Collar
1
23
6125A
Fixed Tight Collar
1
24
6126A
Fixed Tight Collar
1
25
HB809
Nut
5/8”
3
26
W019
Washer
3
27
2402056
Fixed Bolt
3
28
2450056
Name Plate
1
28
2450056A
Name Plate
1
