Scantool 40BK - Parts List for Model 40 Bk

22
Parts List for model 40 BK
CODE
NO
PART NO
DESCRIPTION
SPECIFICATION
QTY
NOTE
1
2401011S
Head Body Set
1
2
2401001-2
Main Shaft Cover
1
3
6101
Chuck Arbor Bolt
MT3 M10xP1.5
1
3
6101-1
Chuck Arbor Bolt
MT3 M12xP1.75
1
3
6101-2
Chuck Arbor Bolt
MT3 W3/8”-16
1
3
6101-3
Chuck Arbor Bolt
MT3 W1/2”-12
1
3
6101-4
Chuck Arbor Bolt
R8 W7/16”-20
1
3
6101-5
Chuck Arbor Bolt
NT30 M12xP1.75
1
3
6101A
Chuck Arbor Bolt
MT4
1
4
HS207
Hex. Socket Head Screw
M4.0x0.7P6L
2
For CE Only
5
HW102
Spring Washer
M4
2
For CE Only
6
Motor
1
7
S409
Hex. Socket Head Screw
3/8”-16UNCx1”L
3
8
HK027
Key
6x6x30L
1
9
6112
Rubber Flange
1
10
6513
Feed Base
1
11
6116-2S
Pinion Assembly
MT3
1
11
6116-3S
Pinion Assembly
MT3 Heat treatment
1
11
6116-6S
Pinion Assembly
R8
1
11
6116BS
Pinion Assembly
R8 Heat treatment
1
11
6116-2NS
Pinion Assembly
NT30
1
11
6116-2SS
Pinion Assembly
1
Optional
11
6116-2BS
Pinion Assembly
MT4
1
11-1
6114
Locknuts
2
11-2
HW205
Washer
AW06 § 30
1
11-3
CA30206J
Taper Roller Bearing
E30206J
1
11-4
6116-2
Rack Sleeve
MT3
1
11-4
6116-3
Rack Sleeve
MT3 Heat treatment
1
11-4
6116-6
Rack Sleeve
R8
1
11-4
6116B
Rack Sleeve
R8 Heat treatment
1
11-5
CA30207J
Taper Roller Bearing
30207J
1
11-6
6117
Spindle Shaft
MT3
1
11-6
6117-1
Spindle Shaft
MT3 Heat treatment
1
11-6
6117-2
Spindle Shaft
R8
1
11-6
6117-3
Spindle Shaft
NT30
1
11-6
6117-6
Spindle Shaft
R8 Heat treatment
1
11-6
2401017B
Spindle Shaft
MT4 Heat treatment
1
11-7
6119
Bearing Cap
MT3/MT4/R8
1
11-7
6119-1
Bearing Cap
NT30
1
12
6554S
Graduated Rod Set
1
13
6193
Hex. Socket Headless Screw
1
14
S008
Hex. Head Screw
¼”x2”L
1
15
N003
Hex. Nut
¼”
1
16
6192
Position Set Bracket
1
17
61105S
Spring Base Set
1
19
S732
Cross Round Head Screw
3/16”x3/4”L
3
20
61103S
Spring Cover Set
1
21
W202
Spring Washer
¼”x1”x1.5t
2
22
W003
Washer
¼”
1
23
6185
Plum Screw
1
23
S471
Hex. Socket Head Screw
¼”x5/8L
1
24
6127
Screw Key
3/8”-16UNC-38L
1
25
N005
Hex. Nut
3/8”
1
26
2421003
Handle Rod
1
27
W002
Washer
½”x7/8”2t
1
28
6125-2
Fixed Tight Collar
1
29
6125A
Fixed Tight Collar
1
