Seite 14
The machine is only drip-proof. Therefore do not use high pressure
cleaning devices, water hoses or similar devices. Furthermore you
must not pour water over the machine. Danger of short circuit or
machine defect. In such cases any claims regarding warranty will be
refused.
4.2. Cleaning the single parts
Clean all removed parts separately with warm water. Wash them up with clear
water and dry them. See also chapter 6. Cleaning.
4.3. Cleaning the blade
Attention! Risk of getting hurt!
clean the inside of the blade with a wet cloth from the centre towards the
edge.
Proceed for the backside of the blade in the same way.
Dry the inside and the backside of the blade carefully.
1. Put a moist cloth between the blade and the fixed protecting ring.
2. Turn the blade by hand one complete rotation and push the moist cloth against the protecting ring
while turning.
1. 2.
4.4. Reassembling the parts
Reassemble the parts in reverse order. (4.3. -> 4.1).
Attention! Risk of getting hurt!
Reassemble the parts with concentration
Do not let distract yourself from your work
Place the splice bar of the blade guard onto the plastic bolt.
Turn the blade guard to the blade and see to it that the flange of the
blade guard is positioned in the centre of the blade.
Tighten the blade guard by turning the star knob clockwise by hand.
Do not use force.
Turn the carriage back.
Tighten the star knob of the carriage.
Mount the end piece holder plate
Screw tight the star knob
Insert the weighing tray with the slots from above into the holder
