Scheppach DP3000 Instruction Manual

 www.scheppach.com  service@scheppach.com  +(49)-08223-4002-99  +(49)-08223-4002-58
21 I 108
2. Device description
Fig.1-20
1. Throttle Control
2. Engine Switch
3. Right Steering Lever
4. Clutch Control Lever
5. Left Steering Lever
6. Fixation dump box
7. Gear Selection Lever
8. Dump Box
9. Gearbox
10. Wheel
Engine components
11. Throttle
12. Exhaust
13. Spark plug
14. Air lter
15. Petrol valve
16. Choke lever
17. Recoil starter
18. Handle Recoil starter
19. Mounting screw service port
20. Fuel cap
21. Fuel tank
22. Oil drain plug motor oil
23. Oil ller opening / oil dipstick
24. Drive chain
25. Spark plug connector
26. Adjusting device
27. Counter nut
28. Oil drain plug gear unit
29. Oil ller gear oil unit
3. Scope of delivery
Dumper DP3000
Manual,
Plastic bag with mounting material
• Open the packaging and remove the device care-
fully.
• Remove the packaging material as well as the pack-
aging and transport bracing (if available)
• Check that the delivery is complete.
• Check the device and its spare parts for possible
damage caused by transportation. In the event of
complaints, you must contact the distributor without
delay. Claims at a later stage will not be accepted.
• If possible, store the packaging until the warranty pe-
riod has expired
• Before handling the device, make yourself familiar
with it by reading the operating instructions.
• For accessories, consumables and spare parts, only
use original parts. Spare parts are available from
your stockist.
• Include our item number, the device model and year
of manufacture in your order.
1. Introduction
Manufacturer:
scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear customer,
We hope you have a lot of fun and success using your
new machine.
Note:
According to the applicable product liability laws, the
manufacturer of the device does not assume liability for
damages to the product or damages caused by the prod-
uct that occurs due to:
• improper handling,
• noncompliance of the operating instructions,
• repairs by third parties, not by au-
thorized service technicians,
• installation and replacement of
non-original spare parts,
• non-intended use,
• A breakdown of the electrical system
that occurs due to the non-compliance of
the electric regulations and VDE regula-
tions 0100, DIN 57113 / VDE0113.
We recommend:
that you read through the entire operating instructions
before putting the machine into operation.
These operating instructions are to assist you in getting
to know your machine and utilize its proper applications.
The operating instructions contain important notes on
how you work with the machine safely, expertly, and
economically, and how you can avoid hazards, save re-
pair costs, reduce downtime and increase the reliability
and service life of the machine. In addition to the safety
requirements contained in these operating instructions,
you must be careful to observe your country’s applicable
regulations.
The operating instructions must always be near the ma-
chine. Put them in a plastic folder to protect them from
dirt and humidity. They must be read by every operator
before beginning work and observed conscientiously.
Only persons who have been trained in the use of the
machine and have been informed of the various dangers
may work with the machine. The required minimum age
must be observed. In addition to the safety requirements
in these operating instructions and your country’s ap-
plicable regulations, you should observe the generally
recognized technical rules concerning the operation of
identical machines.

Scheppach DP3000 Specifications

General

Fuel type	Gasoline
Motor power	6.5 hp
Product type	Motorized wheelbarrow
Maximum power	- W
Number of wheels	4 wheel(s)
Fuel tank capacity	3.6 L
Engine displacement	196 cm³
Maximum load weight	300 kg
Engine number of strokes	-

Weight and Dimensions

Depth	1380 mm
Width	700 mm
Height	1000 mm
Weight	147400 g
