26 GB
• Important! Support long workpieces (e.g. with a roll-
er table) to prevent them sagging at the end of a cut.
• Make sure the blade guard (3) is in its lower posi-
tion when the saw is being transported.
• Safety guards are not to be used to move or mis-
use the machine.
• Blades that are misshapen or damaged in any way
must not be used.
• If the table insert is worn, replace it.
• Never operate the machine if either the door pro-
tecting the blade or the detachable safety device
are open.
• Ensure that the choice of blade and the selected
speed are suitable for the material to be cut.
• Do not begin cleaning the blade until it has come
to a complete standstill.
• For straight cuts of small workpieces against the
longitudinal limit stop the push stick has to be used.
• The bandsaw blade guard should be in its lowest
position close to the bench during transport.
• For miter cuts when the table is tilted, the parallel stop
must be positioned on the lower part of the table.
• When cutting round timber, use a suitable holding
device to prevent the workpiece turning.
• Never use guards to lift or transport items.
• Ensure that the bandsaw blade guards are used
and correctly adjusted.
• Keep your hands a safety distance away from the
bandsaw blade. Use a push stick for narrow cuts.
• The push stick has to be stored on the intended de-
vice, so that it can be reached from normal working
position and is always ready to be used.
• In the normal operating position the operator is in
front of the machine.
• When sawing wood, connect the band saw to a
dust collection device.
• When cutting round or irregularly shaped wood,
use a suitable holding device that prevents the
workpiece from twisting.
6. Technical data
Electro motor
220 - 240 V ~, 50
Hz
Power 550W (S2 20min)
Revolutions 1400 min
-1
Saw band length 1790 mm
Saw band width 6 mm
Saw band width max. 13 mm
Saw band speed I 660 m/min
Saw band speed II 960 m/min
Cutting height 0 - 120 mm
Opening width 245 mm
Table size 300 x 300 mm
Slewing range of the table 0° bis 45°
Werkstückgröße max. 580x400x120 mm
Gewicht 24 kg
The work piece must have a minimum height of 3mm
and a minimum width of 10 mm.
* Duty type S2 – Short-time duty.
Operation at constant load for 20minutes or less, fol-
lowed by a time de-energized and at rest of sufcient
duration to re-establish machine temperatures within
2 K of the ambient temperature.
The total noise values determined in accordance
with EN 61029.
sound pressure level L
pA
77,4 dB(A)
uncertainty K
pA
3 dB
sound power level L
WA
90,4 dB(A)
uncertainty K
WA
3 dB
Wear hearing protection.
The effects of noise can cause a loss of hearing.
Total vibration values (vector sum - three directions)
determined in accordance with EN 61029.
7. Remaining hazards
The machine has been built using modern technolo-
gy in accordance with recognized safety rules. Some
remaining hazards, however, may still exist.
• Risk of injury for ngers and hands by the rotating
saw band due to improper handling of the work piece.
• Risk of injury through the hurling work piece due
to improper handling, such as working without the
push stick.
• Risk of damaging your health due to wood dust and
wood chips. Wear personal protective cloth such
as goggles. Use a tting dust extractor.
• Risk of injury due to defective saw band. Regu-
larely check saw band for such defects.
• Risk of injury for ngers and hands while changing
saw band. Wear proper gloves.
• Risk of injury due to starting saw band while
switching on the machine.
• The use of incorrect or damaged mains cables can
lead to injuries caused by electricity.
• Wear only closetting clothes. Remove rings,
bracelets and other jewelry.
• For the safety of long hair, wear a cap or hair net.
Even when all safety measures are taken, some
remaining hazards which are not yet evident may
still be present.
• Remaining hazards can be minimized by follow-
ing the instructions in „General safety instructions“
„Proper Use“ and in the entire operating manual.
