• Data from the motor‘s rating plate
Machine connection
Only ever use machine connection cables which are
not damaged. The machine connection cable must
not exceed 50 m because otherwise the performance
of the electric motor is reduced. The machine con-
nection cable must have a cross section of 3 x 1.5
mm. Machine connection cables are particularly of-
ten subject to insulation damage. Causes include:
• Cuts when the connection is run over;
• Pinching when connections are guided through
windows and doors;
• Tears from ageing insulation;
• Kinks due to inappropriate attachment or guidance
of the connection.
The machine connection cables have to be at least
type H05RN-F and three-core. Printing the type des-
ignation on the connection is the law. Only ever buy
cables with the designation marked!
The plugs and coupling boxes on the machine con-
nection cables have to be made of rubber and be
protected against spray water. The cables must not
be over-long. Longer cables require larger conductor
cross sections. Power cords and connection cables
have to be checked regularly for damage. Make sure
that the connections are turned off during checking.
Unwind the connection cable fully. Also check cable
inputs, on plugs and coupling boxes, for kinks.
13. Disposal and recycling
The equipment is supplied in packaging to prevent it
from being damaged in transit. The raw materials in
this packaging can be reused or recycled. The equip-
ment and its accessories are made of various types
of material, such as metal and plastic. Defective
components must be disposed of as special waste.
Ask your dealer or your local council.
• Temporary voltage uctuations can be caused in
the machine in the event of unfavourable mains
conditions.
• The product must exclusively be connected to
points which
a) do not exceed a maximum permitted supply im-
pedance „Z“ (Zmax = 0.382 Ω) or
b) have a continuous current rating of at least 100
A per phase.
• As the user, you have to ensure that, if required in
consultation with your energy supplier, the connec-
tion point from which you would like to operate the
product complies with one of the two specied re-
quirements a) or b).
Important notices
If there is a motor overload, it will turn off automati-
cally. After a cool-down period (timing varies), the
motor can be turned on again.
Defective electrical connections
Insulation damage often occurs on electrical con-
nections.
Causes can include:
• Pressure marks when connections are guided
through windows and doors
• Kinks due to inappropriate attachment or guidance
of the connection
• Cuts when the connection is run over
• Insulation damage when being pulled out of the
wall socket
• Tears from ageing insulation
m DANGER
Such defective electrical connections must not be
used and are dangerous to life because of the insu-
lation damage.
Regularly check electrical connections for damage.
Make sure the cable is not connected to the mains
when checking.
Electrical connections must comply with relevant
VDE and DIN stipulations. Only use connections
marked H05VV-F.
Printing the type designation on the connection ca-
ble is the law.
AC motor
• The power voltage has to be 220 – 240 V ~.
• Extension leads up to a length of 25 m must have a
cross section of 1.5 square mm.
Connections and repairs to the electrical equipment
must be carried out by a trained electrician.
If there are any questions, please provide the fol-
lowing data:
• Motor’s type of power
• Data from the machine’s rating plate
