Scheppach HP2200S User Manual

www.scheppach.com
GB
|
35
15. Disposal and recycling
The equipment is supplied in packaging to pre-
vent it from being damaged in transit. The raw
materials in this packaging can be reused or
recycled.
The equipment and its accessories are made
of various types of material, such as metal and
plastic. Defective components must be disposed of as
special waste. Ask your dealer or your local council.
• Check and set the electrode gap. To make sure that
the engine remains e󰀩cient, the spark plug (8) must
have the right electrode gap (0.7-0.8 mm).
• Manually screw the spark plug (8) in and tighten it
with the spark plug spanner (g) approximately 1/4 of
a revolution.
• Place the spark plug connector on the spark plug (8).
Cleaning the oat chamber, (g. Z)
m ATTENTION! Only remove the oat chamber when
the engine is cold!
1. Close the fuel valve (11).
2. Loosen the drain plug (t) on the oat chamber and
drain the fuel into a suitable container.
3. Attach the drain plug (t) again
4. Loosen the fastening screw (u) of the oat cham-
ber.
5. Unscrew the oat chamber and radial seal and
thoroughly clean them in a non-ammable solvent
and let them dry. Check the radial seal for dents
and damage.
6. Screw both parts back on.
7. Screw on the fuel valve (11) and check it for leaks.
Please provide the following information in the
event of any enquiries:
• Machine data - type plate
• Engine data - type plate
Important hint in case of sending the plates to a
service station:
Due to security reasons please see to it that the vibra-
tory plates are sent back free of oil and gas!
Service information
Please note that the following parts of this product are
subject to normal or natural wear and that the following
parts are therefore also required for use as consum-
ables.
Wear parts*: Spark plug, oil, belt, rubber pad, air lter
* Not necessarily included in the scope of delivery!
Spare parts and accessories can be obtained from our
service centre. To do this, scan the QR code on the
cover page.

Scheppach HP2200S Specifications

General

Product type	Vibratory plate
Travel speed	25 m/min
Plate material	Steel
Compaction depth	35 cm
Compaction force	25000 N
Fuel tank capacity	3.5 L
Engine displacement	196 cm³
Engine power	6.5 hp
Power source type	Gasoline

Weight and Dimensions

Depth	1025 mm
Width	440 mm
Height	930 mm
Weight	102000 g
Plate depth	550 mm
