• If possible, please keep the packaging until the end
of the guarantee period.
IMPORTANT
The equipment and packaging material are not toys.
Do not let children play with plastic bags
foils or small parts. There is a danger of swallowing
or suffocating!
■ Fretsaw
■ Saw blade guard
■ Blow-off device
■ Spare saw blade (for wood and plastics)
■ Allen key, 3 mm
■ Allen key, 4 mm
■ Original operating instructions
4. Proper use
The fretsaw was designed to cut square-edged tim-
ber or wood-like workpieces such as Plexiglas, glass
ber reinforced plastic, foam, rubber, leather, and
cork. Do not use this saw to cut round materials.
Round materials can easily become jammed. Risk of
injury! Parts can be catapulted!
The equipment may only be used for the tasks it is
designed to handle. Any other use is deemed to be a
case of misuse. The user/operator and not the manu-
facturer will be liable for any damage or injuries of any
kind caused as a result of this.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial appli-
cations. Our warranty will be voided if the equipment
is used in commercial, trade or industrial businesses
or for equivalent purposes.
• The equipment is to be operated only with suitable
saw blades. It is prohibited to use any type of cut-
ting-off wheel.
• To use the equipment properly you must also ob-
serve the safety information, the assembly instruc-
tions and the operating instructions to be found in
this manual.
• All persons who use and service the equipment
have to be acquainted with these operating instruc-
tions and must be informed about the equipment’s
potential hazards.
• It is also imperative to observe the accident preven-
tion regulations in force in your area.
• The same applies for the general rules of health
and safety at work.
• The manufacturer will not be liable for any changes
made to the equipment nor for any damage result-
ing from such changes.
Residual risks
Even if you use this electric power tool in accordance
to instructions, certain residual risks cannot be elimi-
nated. The following hazards may arise in connection
with the equipment’s construction and layout:
1. Introduction
Important.
When using the equipment, a few safety precautions
must be observed to avoid injuries and damage.
Please read the complete operating instructions and
safety information with due care. Keep these operat-
ing instructions in a safe place so that the information
is available at all times. If you give the equipment to
any other person, hand over these operating instruc-
tions and the safety information as well. We cannot
accept any liability for damage or accidents which
arise due to a failure to follow these instructions and
the safety information.
2. Layout (Figs. 1-12)
1 Blow-off device
2 Mounting
3 Knurled screw
4 Holder
5 Saw blade guard
6 Saw table
7 Cover, left
8 Bearings
9 Tightening lever
10 Arm
11 Graduated scale
12 Locking lever
13 Extractor connection
14 ON/OFF switch
15 Speed regulator
16 Assembly points
17 2x sawblade
18 Retaining device
19 Upper adapter
20 Allen key, 3 mm
21 Angle (not included in the scope of delivery)
22 Storage box for saw blades
23 Lower adapter
24 Saw blade holderer, top
25 Saw blade holder, bottom
26 Table insert
27 Pointer
28 Screw
29 Bracket
30 Work lamp
31 ON / OFF switch work lamp
32 Setting gauge for saw blades without pin
3. Supplied package
• Open the packaging and take out the equipment
with care.
• Remove the packaging material and any packaging
and/or transportation braces (if available).
• Check to see if all items are supplied.
• Inspect the equipment and accessories for trans-
port damage.
GB
