12. Troubleshooting
Warning: In the interests of operational safety, always switch off the saw and remove the mains plug before car-
rying out maintenance work.
Fault Possible causes Action
Saw blades break Tension incorrectly set Set the correct tension
Load to great Feed the workpiece more slowly
Incorrect saw blade variety Use the correct saw blades
Workpiece not fed straight Avoid exerting pressure from the side
Motor does not func-
tion
Mains Gable faulty Change faulty parts
Motor faulty Call customer service. Do not attempt to repair the motor
yourself as this should be carried out by trained person-
nel.
Vibration
NOTE: The saw
vibrates slightly when
the motor is running
in normal operation.
Saw incorrectely installed Refer to the instructions given earlier in this manual for
information on installing the saw
Unsuitable underlay The heavier the work bench is,the less the vibration. A
bench made from ply wood always vibrates more than
one made from solid wood. Select the work bench best
suited to your working conditions
The work bench is not screwed
down or is on the motor
Tighten the locking lever (Fig. 2/Item12)
Saw blade swings out
Holders not aligned
straight
Holders not aligned Losen the screws with which the holders are fastenedto
the arm. Align the holders so that they are perpendicular
to each other and retighten the screws.

Scheppach sd1600v Specifications

General

Blade length	134 mm
Throat depth	406 mm
Product color	Black, Blue
Stroke height	50 mm
Idle speed (max)	1700 RPM
Idle speed (min)	500 RPM
Table tilt range	0 - 45 °
Maximum power	120 W
AC input voltage	220-240 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	630 mm
Width	295 mm
Height	370 mm
Weight	12700 g
Table depth	415 mm
Table width	255 mm
