24 B1051302 Rev. B CDR Wireless Installation
Figure 7. Undocking Units for Remote Positioning
Figure 8. USB Interface with Protective Panel Attached
Figure 9. Antenna / Receiver with Protective Panel Attached
Protective
Panel
Protective
Panel
A
ctive Side of
Antenna
(Faces
Patient)
Screws
Securing
Units
