Schick CDR Wireless - Figure 9. USB Interface Base; Figure 10. Antenna; Receiver Base

26 B1051302 Rev. B CDR Wireless Installation
Figure 10. USB Interface Base
Figure 11. Antenna / Receiver Base
Screw holes
used to
secure
Antenna
(1 of 2)
Raised Non-
Skid Pad
(1 of 4)
Slot to Secure
Base
(1 of 2)
Cable
Management
Guide
Raised Non-
Skid Pad
(1 of 3)
Slot to Secure
Base
(1 of 2)
Screw holes
used to
secure USB
Interface
(1 of 2)
