Schindler 3100/3300/6300 J 43402603 / 01 104/269
Copyright © 2017 INVENTIO AG
*) So marked error descriptions are not released officially by R&D. If necessary, contact
a specialist or the Locarno hotline for more information.
0091
ELEVATOR KNE D INTERRUPTED
C1:The car has exceeded the hoistway end limit (for example, KNE_D)
A1:Check why the car has exceeded the hoistway end limit. Check log for
possible previous reported messages. Release elevator from blocked
state (perform reset procedure)
C2:Safety circuit wiring faulty or safety circuit contact(s) defective or bad
adjusted
A2:Check general wiring safety circuit and safety circuit contacts at
corresponding safety circuit section
0099
DIAGNOSTIC CALL *)
This (informative) error message is created when the logging of a diagnostics-
related message requires a call to TACC. It has to be used with some old
telemonitoring devices in order to be able to initiate the call to TACC.
C1:
A1:No action required
Code Car Door Message
0301
DOOR CLOSING
The door wasn't able to close successfully within a certain time limit. As a
typical response a door recovery gets started (repetitive opening and closing of
the door).
C1:Door closed position feedback signal is faulty
A1:Check door closed position contact (for example, KET-S, if present
and not emulated, depending on door type) for dirt or bad mechanical
adjustment.Check general wiring door closed position contact.
C2:Door doesn't move or moves to slow
A2:Check for obstacle or dirt at door blades and guide rails.Check door
mechanism (broken load carrying element, mechanical coupling,
dirt).Check door motor power supply (fuses).
C3:Door close parameter set wrong
A3:Check door close parameter for correct setting
0302
DOOR OPENING
The door wasn't able to open successfully within a certain time limit. As a
typical response a door recovery gets started (repetitive closing and opening of
the door).
C1:Door opened position feedback signal is faulty
A1:Check door opened position contact (for example, KET-O, if present
and not emulated, depending on door type) for dirt or bad mechanical
adjustment.Check general wiring door opened position contact.
C2:See 0301
A2:See 0301
C3:See 0301
A3:See 0301
Code General Message
