Schindler 6300 - Page 180

Schindler 3100/3300/6300 J 43402603 / 01 180/269
Copyright © 2017 INVENTIO AG
Dynamic Single
Brake Test
Downward (Test 64)
Remark
3 Select 'Full Brake Test Down'
–Select
"Start 'Full Brake Test Down" [__/__/14]
– Press
'OK'  [14/__/__]
The door closes
The door remains closed
"Test ready to run"  [14/__/_2]
4 Start 'Full Brake Test Down'
– Press
'OK'
– The car starts a trip to the bottom floor
– HMI display shows a blinking "14"
 [14/__/__]
– The car reaches rated speed
– HMI display shows a blinking "14"
 [14/__/_1]
– The controller triggers an emergency stop below the KSE-D magnet.
Passed: The car has stopped above KSE-D and the HMI displays
‘Full Brake Test Down’ was successful
 [14/_1/__].
Failed: The car has stopped below the KSE-D magnet and the HMI displays
'Full Brake Test Down’ failed
 [14/_0/_5]. The elevator must be put out of
service immediately until the brakes have been replaced and re-tested.
5 Deactivate 'Full Brake Test Down'
– Press ESC  [__/__/14]
6 Deactivate 'Test Mode'
– Press ESC  [20/__/_1]
– Change to
"Deactivate Test Mode"[20/__/_0]
–Press
’OK’  [20/__/__]
– Press
ESC
The elevator performs a synchronization trip.
7 -
No Step
Car load 100 % GQ
Travel speed 100 % VKN
Car travel direction Down
No Step
0
The inspector must have the two test plugs TEST-MGB and TEST-MGB1
(Brake Test Connectors) in his tool box. The plugs are not delivered with the
elevator.
Make sure the load measuring device is enabled.
The ‘Single Brake Test Up’ must not be performed if the ‘Full Brake Test
Up’ was not passed.
