Schlage M420 - Lock Installation and Wiring; Connect Wiring (Standard Model)

7
6 INSTALL LOCK
6a
Install Magnet and Secure with Screws
Actual Size
7 CONNECT WIRING TO BOARD (STANDARD MODEL)
7a
Review Wiring Connections
TB1
Printed Circuit Board
DC Power
DC (+)
DC (-)
From Magnet
7b
Connect Wires to Board
From Door Frame
DC Power Wires
From Magnet
7c
Install Cover
