schmersal PROTECT-PSC - Combined modules

System description
3
Instruction Manual PROTECT-PSC
V 2.6R01 / 04.19
3–51
3.11 Combined modules
3.11.1 General description
Of the combined modules the following 3 types are available
• PSC-S-STP-E inputs for floating sensors
• PSC-S-STP-LC inputs for non-floating sensors
• PSC-S-STP-ELC inputs for floating/non-floating sensors
If the PROTECT-PSC is in mode 3, the combined modules act like a module with
3x2 inputs and 2x2 outputs.
3.11.2 PSC-S-STP-E
Technical data
Position
Description
Name
PSC-S-STP-E
Operating voltage/current
24VDC+/-10% / 70 mA
Fusing
Internal fuse 3.2A(input circuit）4.0A(output
circuit)
Number of safety inputs
3x2 floating
Input resistance
Approx. 4.7 kΩ
Input current
5mA
High/Low level
H: >18V / >3,5mA
L: <4,7V / <0,5mA
Minimum pulse duration for
possible detection
1.4ms (input filter 0.7ms)
Minimum pulse duration for
safe detection
15ms
Number of safety outputs
2x2
Output current
max. 0,5 A ohmic / output
Connection plug
28-pin plug MORIMATSU M820A-07-xx
28-pin plug EMUDEN T7509-28-xx
Dimensions / weight
30 x 100 x 80 mm / (W/H/D) / 185g
T
T
a
a
b
b
l
l
e
e
3
3
-
-
2
2
0
0
T
T
e
e
c
c
h
h
n
n
i
i
c
c
a
a
l
l
d
d
a
a
t
t
a
a
P
P
S
S
C
C
-
-
S
S
-
-
S
S
T
T
P
P
-
-
E
E
