System description
3
Instruction Manual PROTECT-PSC
V 2.6R01 / 04.19
3–3
3.1 Overview
3.1.1 Product range
Module identi-
fication
Name
Description
CPU Module
PSC-CPU-MON
Program memory:
32K Byte for PS; 32K Byte for PN program.
8 inputs for floating sensors, 24 VDC
6 semi-conductor outputs, 24 V DC, 0.5A
CPU Module
PSC-CPU-OP-
MON
Program memory:
32K Byte for PS; 32K Byte for PN program
8 inputs for floating sensors, 24 VDC
6 semi-conductor outputs, 24 V DC, 0.5A
Lithium battery
Rechargeable lithium battery for memory
buffer of the CPU
Base
PSC-Base
Backplane bus of the modules
SUB-Master-
ON
PSC-SUB-MON
8 inputs for floating sensors; 24 VDC
6 semi-conductor outputs; 24 V DC, 0.5A
STOP Input
PSC-S-STP-E
6 inputs for floating sensors; 24 VDC
4 semi-conductor outputs; 24 V DC, 0.5A
STOP Input
PSC-S-STP-LC
6 inputs for non-floating sensors; 24 VDC
4 semi-conductor outputs; 24 V DC, 0.5A
STOP output
PSC-S-STP-ELC
4 inputs for floating sensors; 24 VDC
2 inputs for non-floating sensors, 24 VDC
4 semi-conductor outputs; 24 V DC, 0.5A
Input
PSC-S-IN-E
16 inputs for floating sensors; 24 VDC
Input
PSC-S-IN-LC
16 inputs for non-floating sensors, 24 VDC
Relay Output
PSC-S-Relais
2x2 relay outputs; 24VDC, 4.0 A
Output
PSC-S-OUT
16 semi-conductor outputs, 24 V DC, 0.3A
Operational in-
put
PSC-NS-IN
16 operational inputs, 24 VDC
Operational
outpu
PSC-NS-OUT+
16 operational outputs, 24 VDC
Power
PSC-Power
Voltage supply: DC 24V +/- 10%, max. 2A
Power
PSC-Booster
Voltage supply: DC 24V +/- 10%, max. 2A
Dongle
Sentinel-25P
Hardware dongle (parallel port) for library
processing.
Dongle
Sentinel-USB
Hardware dongle (USB) for library pro-
cessing.
Programming
Software
PROTECT-
PSCsw
Software for PROTECT-PSC (CD-ROM
version)
USB connec-
tion cable
Connection between PC and PROTECT-
PSC
T
T
a
a
b
b
l
l
e
e
3
3
-
-
1
1
P
P
r
r
o
o
d
d
u
u
c
c
t
t
r
r
a
a
n
n
g
g
e
e
Information on the individual modules can be found in the following chapters.
