schmersal PROTECT-PSC - PSC-SUB-MON

System description
3
Instruction Manual PROTECT-PSC
V 2.6R01 / 04.19
3–48
3.10 PSC-SUB-MON
3.10.1 General description
Mode 3
If the PROTECT-PSC is in mode 3, then the SUB-Master module acts like a mod-
ule with 4x2 inputs and 3x2 outputs.
Technical data
Position
Description
Name
PSC-SUB-MON
Operating voltage/current
24VDC+/-10% / 70 mA
Fusing
Internal fuse
Inputs: 3.2A
Outputs: 4.0A
Number of safety inputs
4x2 floating
Input resistance
Approx. 4.7 kΩ
Input current
5mA
High/Low level
H: >18V / >3,5mA
L: <4,7V / <0,5mA
Minimum pulse duration for
possible detection
1.4ms (input filter 0.7ms)
Minimum pulse duration for
safe detection
15ms
Number of safety outputs
3x2
Output current
Max. 0,5 A ohmic / output
Maximum switching voltage
24 VDC
Connection plug
36-pin plug MORIMATSU M820-09-xx
36-pin plug EMUDEN T7509-36-xx
Dimensions / weight
30 x 100 x 80 mm / (W/H/D) / 195g
