The requirements of the CE specification are only complied with if the
tension meter is equipped and operated with equipment supplied by HANS
SCHMIDT & Co GmbH. Certification to the CE specification does not extend
to, and shall be invalid for any other combination. For damage resulting the-
reby we assume no liability.
2.2 Connecting the tension meter
V-Groove
Line Speed
m/min ... max.
Roller
Material
Standard 2000
Hardcoated
aluminium
V-Groove
Line Speed
m/min ... max.
Roller
Material
Standard 6000
Oxide
ceramic
ETX Guide Rollers: ETPX Guide Pins:
2.1 Specifications
1 Tension meter with accumulator
1 USB AC adapter with 4 adapters (EU/US/UK/AUS-NZ)
1 USB cable
1 Tension Inspect 3 Software for PC WIN XP or higher
1 Certificate of compliance with the order 2.1 under EN 10204
1 Operating Instructions
1 Carrying case
2.3 Delivery includes
2.4 Unpacking
Unpack the tension meter and inspect it for any shipping damage. Notices of defect must
be announced immediately, in writing, at the latest within 7 days on receipt of the goods.
Have you read and understood the Operating Instructions, in particular
Chapter 1 “Basic Safety Notices” ?
You are not permitted to operate the tension meter before doing so.
Before working with the instrument you must put on your personal protective
clothing, if necessary. For example, eye protectors, gloves, etc.
To avoid damage do not move the center roller by hand.
Tensions that exceed the tension range of the instrument by more than
100 % may cause permanent damage to the measuring spring and must be
avoided under any circumstances.
3.1 Notes before starting measurement
3 Operations
