SCHOTT Lab 850 - Socket Field Connections

Overview Lab 850
10
ba75890e01 11/2009
1.3 Socket field
CAUTION
Only connect sensors to the meter that cannot return any voltages
or currents that are not allowed (> SELV and > current circuit with
current limiting).
Almost all sensors - in particular SI Analytics GmbH sensors -
fulfill these conditions.
Connectors:
1 pH electrode
2 Reference electrode
3 Temperature sensor
4 Power pack
5 RS 232 interface
1
2
3
4
5
