5.2.2 Module fault active
Fault in active system, which is not caused by a connected element. The list of faults dis-
plays MODACT with an error code (xxx/nn).
The system may be significantly affected. Call the service department/customer service
immediately (necessary information: equipment type and number, customer number,
messages, error codes).
5.2.3 Module fault passive
(fire alarm control panels Integral EvoxX M)
Fault in a redundant system on the passive side. The list of faults displays MODPAS with an
error code (xxx/nn).
The active system is not affected. Call the service department/customer service (neces-
sary information: equipment type and number, customer number, messages, error
codes).
5.2.4 Emergency mode
(fire alarm control panels Integral EvoxX C and Integral EvoxX B)
If the error code xxx/29 is displayed for a fault in the active system, emergency mode is
activated. Operating and indication functions are reduced; fire alarm system functions.
Call the service department/customer service immediately (necessary information: equip-
ment type and number, customer number, messages, error codes).
5.3 Select elements and querying element
states
|Select elements and querying element states
(Depends on programming and authorisation level)
NOTE
An element number has a value in the range of between 1– 65534.
1. Pressing on of the buttons
N
–
Q
selects a list with the individual elements types
(depending on programming and authorisation level).
u Detector zones by pressing the Zone
N
button.
u Outputs by pressing the Output
O
button.
u Additional external signalling systems by pressing the Input
P
button.
u All other types of element, which could not be selected by using one of the other
buttons listed above (e.g. Printer, Battery etc.) by pressing the Other Elements
Q
button.
