5.6.3 Operation of a range of single elements (detector of a
detector zone)
1. Select the element type Zone by pressing the button
N
.
2. Enter number of the detector zone using the numerical buttons of the keypad
X
.
3. Press the slash key (/) to enter the single element hyphen (/).
4. Enter the the first (lowest) number of the detector in the detector zone using the nu-
merical buttons of the keypad
X
.
5. Press the slash key (/) to enter the range hyphen (-). The display switches to range
operation.
6. Enter the the last (highest) number of the detector in the detector zone using the nu-
merical buttons of the keypad
X
.
u Example for detectors 3– 20 of a detector zone 1:
RANGE OPERATION
ZONE 1/3-20
0000 0000 0000 0000 0001
7. Confirm with the enter button D.
8. The selected detectors of the detectors zone can be operated together with the de-
sired command (
d
–
g
).
5.7 Query alarm counter
|Query alarm counter
Pressing the button Menu
a
opens the menu for additional options. Using the scroll
buttons E/F to select the entry ALARMCOUNTER. Pressing the Enter key D shows the
number of alarms that have occurred so far.
