General operations|Fault messages
20 Operating panel Integral MAP|User manual B-HB-0133EN
5.1.1 Filter list view by element types
If a list contains many entries with several element types, you can filter the list and re-
duce the display of entries to a selected element type. The element type is selected be-
fore the list is called up.
1. Pressing on of the buttons
N
–
Q
selects a list with the individual elements types
(depending on programming and authorisation level).
u Detector zones by pressing the Zone
N
button.
u Outputs by pressing the Output
O
button.
u Additional external signalling systems by pressing the Input
P
button.
u All other types of element, which could not be selected by using one of the other
buttons listed above (e.g. Printer, Battery etc.) by pressing the Other Elements
Q
button.
2. Press the buttons
S
–
V
to call up the respective list. The list entries are filtered ac-
cording to the selected element type.
5.1.2 Warnings list
Elements of the fire alarm system, which are to be replaced, trigger a service all message
(the service call LED
o
lights up). Call service department/customer service immediately.
The warnings list shows all elements, that have triggered this message.
1. Pressing the button
W
displays additional lists.
2. Using the scroll buttons E/F to select the entry WARNINGS.
3. Confirm with the enter button D.
5.2 Fault messages
|Fault messages
The
i
LED flashes and the fault’s signal is sounding, if there are faults (Chapter Reset
alarm/fault signal, Page9). The list of faults Faults
T
displays the malfunctioning com-
ponent with element type, element number and where applicable detector zone.
Pressing the button Site Info
J
displays site information. Pressing the button
Additional Information
Y
displays additional information.
There may be an device or system fault or the emergency mode has been activated.
5.2.1 Device fault
Fault in a device connected to the fire alarm control panel (e.g. detector zone, input, out-
put). If the reason for failure is known (e.g. power failure, reconstruction work), disable
the faulty device if necessary. Call the service department/customer service (necessary in-
formation: equipment type and number, customer number, messages, error codes).
