Technical data
16
04.00 | LGZ | Assembly and Operating Manual | en | 389192
3 Technical data
Size 16 32 50
Mechanical operating data
Stroke per jaw [mm] 3 4 7
Weight [kg]
without gripping force maintenance
with gripping force maintenance
0,1
0,1
0,32
0,35
0,95
0,99
Recommended workpiece weight [kg] 0,6 2,25 5,7
Max. permissible finger length [mm] 30 60 80
Max. permitted weight per finger [kg] 0,03 0,08 0,25
Ambient temperature [°C]
Min.
Max.
-10
90
-10
90
-10
90
Min. Federkraft [N]
without gripping force maintenance
with gripping force maintenance AS
with gripping force maintenance IS
-
30
30
-
150
150
-
330
330
Closing force [N]
without gripping force maintenance
with gripping force maintenance AS
with gripping force maintenance IS
120
150
-
450
600
-
1140
1470
-
Opening force [N]
without gripping force maintenance
with gripping force maintenance AS
with gripping force maintenance IS
144
-
174
540
-
590
1320
-
1650
IP rating 40 40 40
