SCHUNK MPG User Manual

13
Montage- und Betriebsanleitung für
Kleiner 2-Finger-Parallelgreifer Type MPG
Assembly and Operating Manual for
small 2-Finger Parallel GripperType MPG
Dichtsatz MPG 25 (Ident-Nr. 370 807) Seal kit MPG 25 (Id.-No. 370 807)
Dichtsatz MPG 32 (Ident-Nr. 370 808)
Seal kit MPG 32 (Id.-No. 370 808)
Pos./item Ident-Nr. / Id.-No. Bezeichnung / Designation Menge / Quantity
23 9611 001 O-Ring / O-ring 13.00 x 1.00 1
24 9610 111 Quad-Ring / Square-ring 8.20 x 1.78 1
25 9610 001 Quad-Ring / Square-ring 5.28 x 1.78 1
92 9611 054 O-Ring / O-ring 3.00 x 1.00 2
Pos./item Ident-Nr. / Id.-No. Bezeichnung / Designation Menge / Quantity
23 9611 149 O-Ring / O-ring 16.00 x 1.00 1
24 9610 007 Quad-Ring / Square-ring 12.42 x 1.78 1
25 9610 005 Quad-Ring / Square-ring 6.07 x 1.78 1
92 9611 054 O-Ring / O-ring 3.00 x 1.00 2
Dichtsatz MPG 80 (Ident-Nr. 5516 930)
Seal kit MPG 80 (Id.-No. 5516 930)
Pos./item Ident-Nr. / Id.-No. Bezeichnung / Designation Menge / Quantity
23 9907 475 O-Ring / O-ring 8 x 1 1
24 9610 063 Quad-Ring / Square-ring 29.82 x 2.62 1
25 9610 091 Quad-Ring / Square-ring 9.25 x 1.78 1
92 9611 163 O-Ring / O-ring 4.00 x 1.00 2
Dichtsatz MPG 40 (Ident-Nr. 370 809)
Seal kit MPG 40 (Id.-No. 370 809)
Dichtsatz MPG 50 (Ident-Nr. 370 866) Seal kit MPG 50 (Id.-No. 370 866)
Dichtsatz MPG 64 (Ident-Nr. 370 867)
Seal kit MPG 64 (Id.-No. 370 867)
Pos./item Ident-Nr. / Id.-No. Bezeichnung / Designation Menge / Quantity
23 9611 115 O-Ring / O-ring 18.00 x 1.00 1
24 9610 009 Quad-Ring / Square-ring 15.60 x 1.78 1
25 9610 111 Quad-Ring / Square-ring 8.20 x 1.78 1
92 9611 054 O-Ring / O-ring 3.00 x 1.00 2
Pos./item Ident-Nr. / Id.-No. Bezeichnung / Designation Menge / Quantity
23 9907 474 O-Ring / O-ring 22.00 x 1.00 1
24 9936 054 Quad-Ring / Square-ring 20.35 x 1.78 1
25 9610 111 Quad-Ring / Square-ring 8.20 x 1.78 1
92 9611 054 O-Ring / O-ring 3.00 x 1.00 2
Pos./item Ident-Nr. / Id.-No. Bezeichnung / Designation Menge / Quantity
23 9907 605 O-Ring / O-ring 25.00 x 1.00 1
24 9610 261 Quad-Ring / Square-ring 23.52 x 1.78 1
25 9610 111 Quad-Ring / Square-ring 8.20 x 1.78 1
92 9611 054 O-Ring / O-ring 3.00 x 1.00 2
10.2 Beipacks
Beipack MPG 10
10.2 Accessories supplied
Accessories supplied MPG 10
Pos./item Ident-Nr. / Id.-No. Bezeichnung / Designation Menge / Quantity
91 9941 547 Zentrierhülse / Centering sleeve Ø 2 2
Beipack MPG 12 Accessories supplied MPG 12
Pos./item Ident-Nr. / Id.-No. Bezeichnung / Designation Menge / Quantity
91 9941 628 Zentrierhülse / Centering sleeve Ø 2.5 2
Beipack MPG 16 Accessories supplied MPG 12
Pos./item Ident-Nr. / Id.-No. Bezeichnung / Designation Menge / Quantity
91 9941 629 Zentrierhülse / Centering sleeve Ø 3 2
