Montage- und Betriebsanleitung für
2-Finger-Parallelgreifer Type PGN-plus
Assembly and Operating Manual for
2-Finger Parallel Gripper Type PGN-plus
10. Dichtsatz- und Ersatzteilstücklisten
10.1 Dichtsatzlisten
10. Seal kit and spare part lists
10.1 Seal kit lists
PGN-plus 50 Ident-Nr. 370 891 PGN-plus 50 Id.-No. 370 891
Pos./item Ident-Nr. / Id.-No. Bezeichnung / Description Menge / Quantity
30 9610 054 Quad-Ring / Square ring 107.54 x 3.53 1
31 9610 037 Quad-Ring / Square ring 28.17 x 3.53 1
32 9938 995 O-Ring / O-ring 125.00 x 2.00 1
33 9936 334 O-Ring / O-ring 14.00 x 1.50 2
34 9611 063 O-Ring / O-ring 6.00 x 1.00 4
Pos./item Ident-Nr. / Id.-No. Bezeichnung / Description Menge / Quantity
30 9610 072 Quad-Ring / Square ring 85.32 x 3.53 1
31 9610 036 Quad-Ring / Square ring 25.00 x 3.53 1
32 9938 478 O-Ring / O-ring 105.00 x 2.00 1
33 9935 303 O-Ring / O-ring 14.00 x 1.00 2
34 9611 227 O-Ring / O-ring 5.00 x 1.00 4
Pos./item Ident-Nr. / Id.-No. Bezeichnung / Description Menge / Quantity
30 9935 921 Quad-Ring / Square ring 66.34 x 2.62 1
31 9610 021 Quad-Ring / Square ring 20.29 x 2.62 1
32 9936 847 O-Ring / O-ring 76.00 x 1.50 1
33 9935 302 O-Ring / O-ring 11.00 x 1.00 2
34 9611 227 O-Ring / O-ring 5.00 x 1.00 4
Pos./item Ident-Nr. / Id.-No. Bezeichnung / Description Menge / Quantity
30 9936 343 Quad-Ring / Square ring 50.47 x 2.62 1
31 9610 018 Quad-Ring / Square ring 16.20 x 2.62 1
32 9935 467 O-Ring / O-ring 60.00 x 1.50 1
34 9611 227 O-Ring / O-ring 5.00 x 1.00 4
Pos./item Ident-Nr. / Id.-No. Bezeichnung / Description Menge / Quantity
30 9610 028 Quad-Ring / Square ring 39.34 x 2.62 1
31 9610 008 Quad-Ring / Square ring 14.00 x 1.78 1
32 9936 628 O-Ring / O-ring 49 x 1 1
34 9611 163 O-Ring / O-ring 4.00 x 1.00 4
Pos./item Ident-Nr. / Id.-No. Bezeichnung / Description Menge / Quantity
12 9937 444 Flachdichtung / Flat seal PGN-plus 80 1
30 9910 063 Quad-Ring / Square ring 29.82 x 2.62 1
31 9610 007 Quad-Ring / Square ring 12.42 x 1.78 1
Pos./item Ident-Nr. / Id.-No. Bezeichnung / Description Menge / Quantity
12 9937 443 Flachdichtung / Flat seal PGN-plus 64 1
30 9936 629 Quad-Ring / Square ring 21.89 x 2.62 1
31 9610 111 Quad-Ring / Square ring 8.20 x 1.78 1
Pos./item Ident-Nr. / Id.-No. Bezeichnung / Description Menge / Quantity
12 9938 123 Flachdichtung / Flat seal PGN-plus 50 1
30 9610 125 Quad-Ring / Square ring 18.77 x 1.78 1
31 9610 005 Quad-Ring / Square ring 6.07 x 1.78 1
PGN-plus 40 Ident-Nr. 5516 793 PGN-plus 40 Id.-No. 5516 793
Pos./item Ident-Nr. / Id.-No. Bezeichnung / Description Menge / Quantity
12 9942 038 Flachdichtung / Flat seal PGN-plus 40 1
30 9611 010 O-Ring / O-ring 15.60 x 1.78 1
31 9611 227 O-Ring / O-ring 5.00 x 1.00 1
PGN-plus 64 Ident-Nr. 370 892 PGN-plus 64 Id.-No. 370 892
PGN-plus 80 Ident-Nr. 370 893 PGN-plus 80 Id.-No. 370 893
PGN-plus 100 Ident-Nr. 370 894
PGN-plus 125 Ident-Nr. 370 895
PGN-plus 100 Id.-No. 370 894
PGN-plus 125 Id.-No. 370 895
PGN-plus 160 Ident-Nr. 370 896 PGN-plus 160 Id.-No. 370 896
PGN-plus 200 Ident-Nr. 370 897 PGN-plus 200 Id.-No. 370 897
PGN-plus 240 Ident-Nr. 370 987 PGN-plus 240 Id.-No. 370 987
Air-Oil Systems, Inc. www.airoil.com

SCHUNK PGN-plus Series Specifications

General

Material	Aluminum, steel
Gripper Type	Parallel Gripper
Repeatability	±0.01 mm
Operating Pressure	2 to 8 bar
Opening Time	0.1-0.5 s
Ambient Temperature	5 °C
