SCHUNK PGN-plus Series User Manual

26
Montage- und Betriebsanleitung für
2-Finger-Parallelgreifer Type PGN-plus
Assembly and Operating Manual for
2-Finger Parallel Gripper Type PGN-plus
* Einzelteile sind aufeinander abgestimmt und können nicht vom Kunden
ausgetauscht werden.
GKS: Greifkraftsicherung
AS: Außensichern
IS: Innensichern
SD: Staubabdeckung
KVZ: Kraftverstärkungszylinder
HUE: Schutzhülle
* Individual components are matched to one another so that the customer
should not replace them with different parts.
GKS: Gripping force safety device
AS: Safety device O.D. gripping
IS: Safety device I.D. gripping
SD: Dust Cover
KVZ: Power booster cylinder
HUE: Protective cover
Verschleißteile, empfohlen bei Wartung auszutauschen Wear parts; replacement during maintenance recommended
Pos./item Ident-Nr. / Id.-No. Bezeichnung / Description Menge / Quantity
6 5511 497 Zylinderkolben ohne GKS - GKS IS / Cylinder piston without GKS - GKS IS 1
7* 5511 505 Grundbacke - Hub 2 / Base jaw - Stroke 2 2
8 5511 507 Kolben - Hub 2 / Piston - Stroke 2 1
9 5511 509 Deckel GKS / Cover GKS 1
10 5511 510 Zylinderkolben GKS AS / Cylinder piston GKS AS 1
11 5511 487 Distanzbolzen GKS AS / Distance bolt GKS AS 1
15 9937 475 Schaltnocke / Operating cam 2
16 9936 956 Halter für Schaltnocke / Bracket for operating cam 2
17 5503 506 Halter für Näherungsschalter / Bracket for proximity switch 2
19 5509 645 Zentrierhülse Ø 14 - GKS / Centering sleeve Ø 14 - GKS 2
25 9937 955 Druckfeder GKS AS / Pressure spring GKS AS 1
25 9937 956 Druckfeder GKS IS / Pressure spring GKS IS 1
30 9941 9087 O-Ring / O-ring 85.32 x 3.53 1
31 9610 036 Quad-Ring / Square ring 25.00 x 3.53 1
32 9936 043 O-Ring / O-ring 106.00 x 2.00 1
33 9935 303 O-Ring / O-ring 14.00 x 1.00 - ohne/without GKS - GKS IS 1
33 9935 303 O-Ring / O-ring 14.00 x 1.00 - GKS AS 2
34 9611 227 O-Ring / O-ring 5.00 x 1.00 4
40 9664 033 Senkschraube / Countersunk screw M12 x 30 - ohne/without GKS - GKS IS 1
41 9907 607 Schraube / Screw M5 x 16 - ohne/without GKS 8
42 9938 231 Schraube / Screw M4 x 30 - Hub / Stroke 1 2
42 9907 483 Schraube / Screw M4 x 25 - Hub / Stroke 2 2
43 9660 219 Schraube / Screw M4 x 25 - Hub / Stroke 1 2
43 9660 136 Schraube / Screw M4 x 20 - Hub / Stroke 2 2
44 9660 413 Schraube / Screw M3 x 14 4
45 9660 403 Schraube / Screw M12 x 65 / GKS AS 1
46 9660 422 Schraube / Screw M8 x 50 / GKS 4
47 9664 501 Senkschraube / Countersunk screw M3 x 8 4
48 9936 175 Gewindestift / Set-screw M5 x 4 6
49 9936 175 Gewindestift / Set-screw M5 x 4 4
50 5511 495 Gehäuse mit Grundbacken - Hub 1 / Housing with base jaws - Stroke 1 1
50 5511 503 Gehäuse mit Grundbacken - Hub 2 / Housing with base jaws - Stroke 2 1
60 9938 063 Rundmagnet / Round magnet 1
81 5512 997 Abdeckung / Cover SD 2
82 5513 005 Abdeckblech / Cover plate SD 1
83 5513 013 Zwischendeckel / Intermediate cover SD 2
84 5513 021 Zwischenbacke / Intermediate jaw SD 2
85 5513 024 Dichtbolzen / Sealing bolt SD 2
86 9939 382 Hülse / Sleeve Ø 16 SD 4
87 9611 527 O-Ring / O-ring 50.00 x 1.50 SD 2
89 9664 501 Senkschraube / Countersunk screw M3.0 x 8 SD 8
90 9936 447 Schraube / Screw M5.0 x 8 SD 4
91 9660 044 Schraube / Screw M12.0 x 25.00 SD 4
92 9535 011 Scheibe / Washer 13.0 mm SD 4
98 5512 049 Beipack ohne GKS / Accessories supplied without GKS 1
99 5512 057 Beipack mit GKS / Accessories supplied with GKS 1
