Date Code 20210715 SEL-2890 Instruction Manual

Settings and Commands

Ethernet Network Operation Settings

3.15

your general network implementation and administration plan. See Tab le 3.4 for

examples of how IP and SUBNET_MASK define the network and node and how these

settings affect the GATEWAY setting.

Table 3.4 GATEWAY Address Setting Examples

IP SUBNET_MASK Network Number Node Address GATEWAY

192.92.92.92 255.255.255.0 192.92.92 92 192.92.92.a

Value in the range 0–254.

192.92.92.92 255.255.0.0 192.92 92.92 192.92.a

Value in the range 0–255.

192.92.92.92 255.0.0.0 192 92.92.92 192.a
