Date Code 20210715 SEL-2890 Instruction Manual

Appendix F

Open Network Ports

The following information is intended to help security auditors verify that the network

hosts and open ports on a control network are what is expected.

The following tables list the network ports that may be presented by the device.

Physical Port # Ports Default Can Be Disabled

Serial Ports 1 Enabled No

Ethernet Ports 1 Enabled No

Ethernet

Services:

Server

Device

Function

Protocol

Default

Listening

Port

Settable

Default

State

Can Be

Disabled

Hypertext

Transfer

Protocol

(HTTP)

Relay

Display

TCP 80 No Enabled No

Telnet (Server) Passthrough

Mode

TCP 23 Yes Enabled Yes

Raw TCP

(Server)

Passthrough

Mode

TCP 23 Yes Disabled Yes

Telnet (Server) Console TCP 1025 Yes Enabled No

File Transfer

Protocol (FTP)

Authentica-

tion Proxy

TCP none Yes Enabled No

Internet Control

Message

Protocol (ICMP)

System ICMP N/A N/A Enabled No
