SEL-2890 Instruction Manual Date Code 20210715

Open Network PortsF.2

Ethernet

Services:

Client

Device

Function

Protocol

Default

Destination

Port

Settable

Default

State

Can Be

Disabled

Telnet (Client) Serial Tunnel

Mode

(Telnet)

TCP 23 Yes Disabled Yes

Telnet (Client) Serial Tunnel

Mode (Cmd)

TCP 23 Yes Disabled Yes

Raw TCP

(Client)

Serial Tunnel

Mode

(TCP/BTCP)

TCP 23 Yes Disabled Yes

Dynamic Host

Configuration

Protocol

(DHCP) Client

Networking UDP 68 No Disabled Yes

Simple Mail

Transfer

Protocol

(SMTP)

Optional alerting method to send unsolicited messages coming in from the serial port to an

email address.

Alerting

TCP 25 Yes Disabled Yes

Domain Name

Service (DNS)

Networking UDP 53 No Disabled Yes

Ethernet

Services:

Non-IP

Protocols

Device

Function

Protocol

Default

Destination

Port

Settable

Default

State

Can Be

Disabled

Address

Resolution

Protocol

(ARP)

Networking ARP N/A N/A Enabled No
