SCOPE OF APPLICATION
The present operating instructions are
applicable to FW 24 radio remote-control
units in proportional and digital design
suitable for SCHWING truck-mounted
concrete pumps equipped with control
systems of the "MULTI-Control" and
"COMFORT-Control" type.
The operator panels of the radio
transmitters are the same (with the
e
xception of switch 6, Fig.1) for both control
systems. For detailed description please
refer to chapter 3.
The present manual does not contain
instructions relating to a particular type of
machine.
For machine-specific instructions please
refer to the corresponding machine manual.
MANUFACTURER
FW 24 remote-control units are
manufactured for SCHWING by:
TELETEC GmbH
Paul-Lincke-Ufer 39/40
10999 Berlin
Tel. 030-612 40 45
FAX 030 - 611 50 39
COMFORT-Control
MULTI-Control
Switch 6:
FW24rmbx.eps
0
FW24-ID.eps
POWER
HF1
HF2
Stop
Fig.1
6
1
2
3
4
5
0
