Service Manual
Remote Control Cable/Radio
607
OPERATION AND FAULT INDICATORS (Cont.)
2. RECEIVER
"MULTI-Control" receiver only
MC 1
MC 2
EM 1
EM 2
wrong
pol.
dis-
charge
charge
MESSAGE
valid radio data signals
are being received
EMERGENCY SHUT-
OFF actuated
no reception
battery being finished
battery being charged
battery inserted with
wrong polarity
battery being discharged
machine executes control
commands
set all switches on trans-
mitter to "0", unlock EMER-
GENCY SHUT-OFF button.
change frequency,
choose other location
remove battery from or
leave in charger (trickle
charge)
insert battery correctly
charger switches auto-
matically to normal charge
when the battery is dis-
charged
ACTION
MC 1
MC 2
EM 1
EM 2
wrong
pol.
MESSAGE
built-in control module active
required for servicing purpose only
ACTION
