Schwinn 590e - Parts

10
14
3
2
4
7
8
4
9
3
5
10
11
12
13
1
6
15
16
*
*
*
*
17
A right (“ R ”) and left (“ L ”) decal has been applied to some parts to assist with assembly.
Item Qty Description Item Qty Description
1 1 Console Assembly 10 1 Leg, Right
2 1 Upper Handlebar, Left 11 1 Pedal, Right
3 2 Handlebar Cover, Interior 12 1 Rail Assembly *
4 2 Handlebar Cover, Exterior 13 1 Leg, Left
5 1 Main Assembly * 14 1 Pedal, Left
6 1 Console Mast 15 1 Document Kit
7 1 Console Pivot Cover 16 1 Silicone Lubricant, Bottle
8 1 Upper Handlebar, Right 17 1 Hardware Bag
9 1 Power Cord
DO NOT CUT THE SHIPPING ZIP-TIES on the Rail Assembly or Main Assembly until instructed. *
PARTS
