2. Keeping the Area Clear Along the Short Ends of the Box, Unpack Leaving the Main
Assembly on the Two Lower Shipping Blocks
DO NOT CUT THE SHIPPING ZIP-TIES on the Rail Assembly or Main Assembly until instructed.
Note: Be sure to remove the Shipping Insert Rod from the Incline (Lift) Motor Arm of the Main Assembly before remov-
ing the Upper Shipping Block.
5
12
Lower Shipping
Blocks
Incline (Lift) Motor Arm
Upper Shipping Block
To Next Page
