19
8. Place, Pivot and Secure the Console Assembly to the Console Mast, and Then Connect the
Console Cables
NOTICE: Do not pinch or cut the Cables. Be sure to fully connect the cable connectors. Once connected, push the
Cables into the Console Mast. * Hardware is not supplied in the Hardware Bag.
#2
*
X4
*
*
*
*
