Schwinn IC3 - Pedal and Holder Attachment

11
4. Attach Pedals to Frame Assembly
Note: The Left Pedal is reverse-threaded. Be sure to attach Pedals on the proper side of the Bike. Orientation is based
from a seated position on the bike. The Left Pedal has an “L”, the Right Pedal an “R”.
5. Attach Water Bottle Holder to Handlebar
Note:Thehardware(*)ispre-installedandnotintheHardwareBag.
8
7
9
*
X3
