1.1.3.2 Plug the 5-pin connector of the display to the coupling connector of the
Controller.
1.2 Working Voltage and Cable Connection
1.2.1 Working Voltage
DC24V-72V compatible，other working voltage level can be customized.
1.2.2 Connection
Display to Controller Controller to Display Controller Connector
