Standard Cable Connector Diagram
1.2.3 Extended Functions
Light: Brown (DD): The power wire (+) of the light
White (GND): The ground wire (〨) of the light.
*Note: Some products use waterproof connectors, in which internal wire
arrangements cannot be identified from the exterior.
1.2.4 Specifications
1.2.4.1 Working Voltage: DC 24V/36V/48V/60V/72V
1.2.4.2 Rated Working Current: 12mA
1.2.4.3 Leakage current: <1uA
1.2.4.4 Screen Size: 2.5 ” LCD
1.2.4.5 Communication Type: UART (by default)
1.2.4.6 Working Temperature: -20°C ~ 70°C
1.2.4.7 Storage Temperature: -30°C ~ 80°C
1.2.4.8 Waterproof Rating: IPX6
1.3 Functions
1.3.1 General Description:
G518 provides various functions to facilitate your ride, main functions are:
Sequence No.
Wire Color
Functions
1
Red（VCC）
Display Power Cable
2
Blue（K）
Controller Power Cable
3
Black（GND）
Display Ground Cable
4
Green（RX）
Display Data Receiving Wire
5
Yellow（TX）
Display Data Sending Wire
