C2648 Prodigy and Prodigy Plus Service Manual
January 2015
Page 32
Component Indicator Light Table
System Indicator Light ON
Condenser Fan or Liquid Line Valve LLV open
Water Pump Pump Motor Powered
Purge Valve Purge Valve Opens
Inlet Water Solenoid Valve Inlet Water Valve Opens
Hot Gas Hot Gas Valve Opens
Compressor Contactor Contactor Closes
Ready to Harvest Water contacting ice thickness sensor probe
Sump Empty Open between mid sensor and common
Sump Full Closed between top probe and mid probe
Curtain Switch Curtain open
