Product Description, Electrical Requirements
Ice Machine
Dimensions
w” x d” x h”
Model Electrical Use
condenser
Minimum
Circuit
Ampacity
Maximum
Fuse* Size
Suggested
Fuse* Size
48 x 28 x 31 C2648SR-3 208-230/60/3 PRC241-32A 21.6 30 30
same C2848MR-3 208-230/60/3 PRC241-32A 21.6 30 30
Remote Condenser Footprint: On center mounting hole spread: 27.57” w x 33.38” d. See page 5.
Minimum bin top opening: 20.5” x 40.5” includes drop zones and ultrasonic sensor location. See page 5.
*Or HACR circuit breakers.
Table notes: Series revision code omitted. All the
listed condensers include a headmaster valve.
Ratings include the remote condenser motor, as it
is designed to be powered by the ice machine. If
connecting remote condenser independently of the
ice machine, use the information on the condenser's
dataplate for fuse and wire sizes.
Condensers are UL listed for these model ice
machines.
Central Condenser (Rack) Coils
The ice machine may be connected to a central
condenser coil. The requirements are:
• Coil – not previously used with mineral oil system.
Virgin coil preferred.
• Correct size (internal volume) and capacity (BTUH).
Contact Scotsman for data.
• Includes a headmaster valve for discharge pressure
control rated at 217 PSIG.
• Fan motor on all the time or controlled to be on
whenever the ice machine is operating.
• U.L. listed for the ice machine
• Non-Scotsman condensers must have prior
Scotsman Engineering approval for warranty
coverage to be in effect.
