C2648 Prodigy and Prodigy Plus Service Manual
January 2015
Page 35
Water System
Batch type. Water reservoir contains full water charge for each ice making cycle.
Water valve: Solenoid type. Opens to ll reservoir when mid sensor probe no longer makes a circuit to the
bottom probe. Closes when reservoir is full and top probe makes circuit to mid probe.
Pumps: Unsealed pedestal type, twist-release mounting
Water purge valve: Solenoid type. Opens to purge water during harvest cycle.
Water Level Sensor: Three probe conductivity.
Distributors: ABS plastic. Evenly distributes water over the evaporator surface. Slides off the evaporator top.
Removable cover for ease of cleaning.
Water Distributor Removal
