Connect the negative cable (4) to the negative
terminal of the always from the
positive one (+), and the screws (1).
Refit the cover (A) and tighten screws (B).
Refit the seat as described in chapter “Seat lock”.
The gives explosive gases; never
cause sparks or allow naked flames and
near the When charging the ensure
that the working area is properly ventilated.
Connect the charger leads to the
terminals: the red one to the positive terminal (+),
the black one to the negative terminal (-).
Ducati disclaims any liability deriving from the use of
non-original Ducati chargers or maintainers.
It is recommended to use the Ducati dedicated
charge maintainer Maintenance Kit
no. 69928471A (Europe), no. 69928471AW
(Japan), 69928471AX (Australia), 69928471AY (UK),
69928471AZ (USA), available from our sales
network), and to operate as described in the sub-
section “Maintaining the charge”.
Keep the out of the reach of children.
Before activating the charger, connect
it to the always with the red positive
terminal (+) first.
Should it be impossible to the vehicle due
to a completely flat it is not to
the bike by connecting an external or
and external in parallel.
The charging system, indeed, is not designed to
ensure a correct supply voltage for the engine
electronics (including ignition/injection system) with
a completely flat
This could lead to a serious functional problem.
Please, replace the or recharge it, and check
it before using the bike.
Do not push the bike.
181
