Transmission
Multiplate wet clutch controlled hydraulically on
side of the handlebar.
Drive is from engine to gearbox primary
via spur gears.
6-speed gearbox with constant mesh gears, and gear
change pedal on side of motorcycle.
Primary drive, front / rear sprocket ratio: 33/61.
Final drive, gearbox output front sprocket/rear
sprocket ratio: 15/46.
Total gear ratios:
1
st
gear 13/32
2
nd
gear 18/30
3
rd
gear 21/28
4
th
gear 23/26
5
th
gear 22/22
6
th
gear 26/24
Drive chain from gearbox to rear wheel.
Make: DID
Type: 520VFX103+1 ZB
Size: 5/8" x 1/4"
Links: 104
The above gear ratios are the homologated
ones and under no circumstances must they be
modified.
If the rear sprocket needs replacing, contact a
Ducati Dealer or authorised Service Centre.
If improperly replaced, this component could
seriously endanger your safety, as well as the
passenger one, and cause irreparable damage to
your motorcycle.
217
