Brake disc thickness: 5 mm (0.2 in).
Brake disc thickness (maximum wear): 4.5 mm (0.18
in).
Disc diameter: 330 mm (13 in).
Hydraulically operated by an adjustable control lever
on handlebar right-hand side.
Front brake calliper with radial mount with 4 pistons.
Brake calliper make: BREMBO.
Number of pistons: M4 x 32 b (4x32).
Friction material: TT 2182 FF.
Master cylinder type: PS 13/22 with Adjustable
Lever.
REAR
With fixed drilled steel disc.
Clutch housing material: stainless steel.
Disc diameter: 245 mm (9.6 in).
Brake disc thickness: 4.2 mm (0.2 in).
Brake disc thickness (maximum wear): 3.8 mm (0.15
in).
Floating calliper.
Hydraulically operated by a pedal on RH side.
Make: BREMBO
Number of pistons: PF 32 b (1x32).
Friction material: FERIT I/D 450 FF.
Master cylinder type: PS 11.
The brake fluid used in the brake system is
corrosive.
In the event of accidental contact with eyes or skin,
wash the area with abundant running water.
216
