Tank filler plug
Opening
flap (1) and the key in the lock.
Turn the key clockwise by 1/4 of a turn to release the
lock.
the plug (2).
Closing
Lower the plug (2) with the key and push it
down into its seat.
Turn the key counter clockwise to the original
position and remove it.
Close flap (1).
Note
Plug can only be closed when key is
refuelling, always make sure that the plug
is in place and closed.
Fig 24
Fig 25
49
