no. Description
1 Interactive menu
2 Info display
3 Speed
It is displayed increased by 5% and together with the set unit of measurement (km/h or mph).
4 Fuel level
Available in 2 modes: graduated bar or km or miles remaining.
It is possible to set it through the “Fuel indicator” function in the menu” (page 136).
5 Current Riding Mode
6 Clock
It is possible to set it through the “Date and time” function in the menu” (page 149).
7 Gear
8 Parameters window
It displays the values of the DTC and DQS parameters set for the current Riding Mode.
In case of errors on one or more parameters, “Err” is displayed instead of the relevant value.
9 Rev counter
Refer to “Engine rpm indication” (page 109)
10 Air temperature (°C or °F)
Note
When the motorcycle is stopped, the engine heat could influence the displayed temperature.
98
