Operation & Maintenance Manual──LG946L Wheel Loader
59
the outside lock of the cab and the door will be locked outside the cab. Turn the control bar
downward and it will unlock.
z Inside Cab Locking Bar: When the lock of the cab is in the locked positions, the door will
be locked automatically after closing the door. Insert key outside the cab. Turn
180°clockwise and pull out key. Pull the handle outside the cab and the cab door will open.
Turn the lock bar upward and it will open.
1.2.6 Frame Locking Bar
△! WARNING
z Be sure to use the front and rear frame locking bar during
maintenance or transporting the machine.
z Be sure to release the frame locking bar during routine travel.
z The frame locking bar is used to lock the front and rear frames during maintenance or
transporting vehicles, in order to prevent the frames from moving.
1.2.7 Towing Pin
z During towing, insert the towing pin ① into the counterweight .②
1.2.8 Fuse
To Next Page
